Spanners

TWT - 101

Combination Open & Ring End Spanners Cold Stamped

Description

DIN 3113, Press Panel
Chrome Vanadium Steel
Hardened and Tempered
Each Head set at 15° angle
Available in Matt Finish / Satin Finish

Specification

Size	Length	Qty/Ctn
MM	MM	Pcs.
6	100	600
7	110	600
8	120	400
9	130	400
10	140	400
11	150	300
12	160	300
13	170	240
14	180	200
15	190	200
16	200	200
17	210	150
18	220	150
19	230	120
20	240	100
21	250	100
22	260	100
23	270	60
24	280	60
25	290	60
26	300	60
27	310	50
28	320	50
29	330	50
30	340	40
32	350	40

Packaging

No. of Pcs.	Set	Sizes (MM)	Qty/Ctn (Set)
6 pcs	8-17	8,10,12,13,14,17	60
8 pcs	8-19	8,9,10,11,13,14,17, 19	30
12 pcs	6-22	6,7,8,9,10,11,12,13,14,17,19,22	20
12 pcs	6-24	6,8,9,10,12,13,14,15,17,19,22,24	20
14 pcs	8-32	8,9,10,11,12,13,14,17,19,22,24,27,30,32	8
25 pcs	6-32	6,7,8,9,10,11,12,13,14,15,16,17,18,19,20,21,22,23,24,25,26,27,28,30,32	4

TWT - 102

Combination Open & Ring End Spanners Cold Stamped / Elliptical Pattern

Description

DIN 3113
Chrome Vanadium Steel
Hardened and Tempered
Each Head set at 15° angle
Available in Fully Polished, Matt Finish, Satin Finish

Specification

Size	Qty / Ctn
MM	Pcs.
33	30
34	30
35	20
36	20
37	20
38	20
39	20
40	20
41	20
42	20
44	16
46	16
48	12
50	12

TWT - 103

Combination Open & Ring End Spanners Elliptical Pattern

Description

Elliptical Pattern
Chrome Vanadium Steel
Hardened and Tempered
Each Head set at 15° angle
Available in Mirror Polish / Satin Finish

Specification

Size	Length	Qty/Ctn
MM	MM	Pcs.
6	100	800
7	110	600
8	120	600
9	130	500
10	140	400
11	150	400
12	160	300
13	170	300
14	180	200
15	190	200
16	200	200
17	210	150
18	220	150
19	230	120
20	240	100
21	250	100
22	260	100
23	270	60
24	280	60
25	290	60
26	300	60
27	310	50
28	320	50
29	330	50
30	340	40
32	350	40

Packaging

No. of Pcs.	Set	Sizes (MM)	Qty/Ctn (Set)
6 pcs	8-17	8,10,12,13,14,17	60
8 pcs	8-19	8,9,10,11,13,14,17,19	30
8 pcs	8-19	8,10,12,13,14,15,17,19	30
12 pcs	6-22	6,7,8,9,10,11,12,13,14,17,19,22	20
12 pcs	6-24	6,8,9,10,12,13,14,15,17,19,22,24	20
14 pcs	8-32	8,9,10,11,12,13,14,17,19,22,24,27,30,32	8
25 pcs	6-32	6,7,8,9,10,11,12,13,14,15,16,17,18,19,20,21,22,23,24,25,26,27,28,30,32	4

TWT - 104

Combination Open & Ring End Spanners Elliptical Pattern (Dip Insulation)

Description

Packaging

No. of Pcs.	Set	Sizes (MM)	Qty/Ctn (Set)
8 pcs	8-19	8, 9, 10, 11, 13, 14, 17, 19	30
12 pcs	6-22	6, 7, 8, 9, 10, 11, 12, 13, 14, 17, 19, 22	20
14 pcs	6-32	6, 8, 9, 10, 11, 12, 13, 14, 17,19, 22, 24, 27, 32	10
25 pcs	6-32	6, 7, 8, 9, 10, 11, 12, 13, 14, 15, 16, 17, 18, 19, 20, 21, 22,23, 24, 25, 26, 27, 28, 30, 32	4

TWT - 105

Combination Open & Ring End Spanners (Raised Pattern)

Description

Available in all metric sizes (6-32mm)
Made from Carbn Steel
Hardened and Tempered
Each Head set at 15° angle

Packaging

No. of Pcs.	Set	Sizes (MM)	Qty/Ctn (Set)
12 pcs	6-22	6, 7, 8, 9, 10, 11, 12, 13, 14, 17, 19, 22	20
12 pcs	6-24	6, 8, 9, 10, 11, 12, 13, 14, 17, 19, 22, 24	15

TWT - 106

Combination Open & Ring End Spanners (Recessed Pattern)

Description

Drop Forged From Carbon Steel / Chrome Vanadium Steel
Hardened And Tempered
Each Head Set At 15º Angle
Chrome Plated
Available in Short Pattern / Long Pattern

Specification

Size	Length	Qty/Ctn
MM	MM	Pcs.
6	100	1000
7	105	1000
8	120	1000
9	130	800
10	140	600
11	150	500
12	160	500
13	170	400
14	180	300
15	190	200
16	200	200
17	210	200
18	220	200
19	230	200
20	240	200
21	250	150
22	260	150
23	270	100
24	280	100
25	290	100
26	300	60
27	310	60
28	320	60
29	330	50
30	340	50
32	350	50

Packaging

No. of Pcs.	Set	Sizes (MM)	Qty/Ctn (Set)
8 pcs	8-19	8, 9, 10, 11, 13, 14, 17, 19	40
12 pcs	6-22	6, 7, 8, 9, 10, 11, 12, 13, 14, 17, 19, 22	20
12 pcs	8-24	8, 9, 10, 11, 12, 13, 14, 15, 17, 19, 22, 24	15
25 pcs	6-32	6, 7, 8, 9, 10, 11, 12, 13, 14, 15, 16, 17, 18, 19, 20, 21, 22,23, 24, 25, 26, 27, 28, 30, 32	4

TWT 107 - 108

Double Ended Open Jaw Spanners (Cold Stamped / Elliptical Pattern)

Description

DIN 3110
Chrome & Vanadium Steel
Hardened & Tempered
Each Head Set At 15º Angle

Specification

Size	Length	Qty/Ctn
MM	MM	Pcs.
6x7	122	600
8x9	140	600
10x11	157	300
12x13	172	200
14x15	190	200
16x17	205	150
18x19	222	120
20x22	236	80
21x23	250	80
24x26	266	60
24x27	266	60
25x28	280	60
27x32	302	50
30x32	302	50

Packaging

No. of Pcs.	Set	Sizes (MM)	Qty/Ctn (Set)
8 pcs	6x7 - 20x22	6x7, 8x9, 10x11, 12x13, 14x15, 16x17, 18x19, 20x22	20
12 pcs	6x7 - 30x32	6x7, 8x9, 10x11, 12x13, 14x15, 16x17, 18x19, 20x22, 21x23, 24x27, 25x28, 30x32	12

TWT - 109

Double Ended Open Jaw Spanners

Description

Drop Forged from Carbon Steel / Chrome Vanadium Steel
Hardened and Tempered
Each Head set at 15° angle
Chrome Plated
Available in Short Pattern / Long Pattern

Packaging

No. of Pcs.	Set	Sizes (MM)	Qty/Ctn (Set)
8 pcs	6x7 - 20x22	6x7, 8x9, 10x11, 12x13, 14x15, 16x17, 18x19, 20x22	40
12 pcs	6x7 - 30x32	6x7, 8x9, 10x11, 12x13, 14x15, 16x17, 18x19, 20x22, 21x23, 24x27, 25x28, 30x32	20

TWT - 110

Bi-Hexagonal Ring Spanners

Description

Drop Forged from Carbon Steel / Chrome Vanadium Steel
Hardened and Tempered
Each Head set at 15° angle
Chrome Plated
Available in Short Pattern / Long Pattern

Packaging

No. of Pcs.	Set	Sizes (MM)	Qty/Ctn (Set)
8 pcs	6x7 - 20x22	6x7, 8x9, 10x11, 12x13, 14x15, 16x17, 18x19, 20x22	20
12 pcs	6x7 - 30x32	6x7, 8x9, 10x11, 12x13, 14x15, 16x17, 18x19, 20x22, 21x23, 24x27, 25x28, 30x32	10

TWT 111-112

Bi-Hexagonal Ring Spanners (Cold Stamped / Elliptical Pattern)

Description

DIN 3110
Chrome & Vanadium Steel
Hardened & Tempered
Each Head Set At 15º Angle

Specification

Size	Length	Qty/Ctn
MM	MM	Pcs.
6x7	122	400
8x9	140	320
10x11	157	240
12x13	172	160
14x15	190	120
16x17	205	100
18x19	222	100
20x22	236	80
21x23	250	80
24x26	266	60
24x27	266	60
25x28	280	50
27x32	302	50
30x32	302	40

Packaging

No. of Pcs.	Set	Sizes (MM)	Qty/Ctn (Set)
8 pcs	6x7 - 20x22	6x7, 8x9, 10x11, 12x13, 14x15, 16x17, 18x19, 20x22	12
12 pcs	6x7 - 30x32	6x7, 8x9, 10x11, 12x13, 14x15, 16x17, 18x19, 20x22, 21x23, 24x27, 25x28, 30x32	6
